SP-CFR604 S-Plus Analog IR Camera • Smart look Day/ Night Fixed Dome Camera with IR illuminator • High resolution: 600 TV lines • High sensitivity with Day/ Night function: 0.6 lux( Color) , 0 lux ( B/ W, IR LED is ON) • Digital Noise Reduction • 4 - 9 mm, 2.2x varifocal lens • Wide Coverage: Horizontal: 35º ( Tele) -70º ( Wide) , Vertical : 26º ( Tele) -53º ( Wide) Specifications : Camera Image Sensor 1/ 3 type interline transfer CCD Effective Pixels 976 ( H) x 582 ( V) Scanning Mode 2: 1 interlace Scanning Area 4.8 mm ( H) x 3.6 mm ( V) Scanning frequency Horizontal: 15.625 kHz, Vertical: 50.00 Hz Horizontal Resolution 600 TV lines Minimum Illumination Color: 0.6 lx, B/ W: 0 lx ( IR LED is ON) at F1.6 IR LED Light Auto IR LED irradiation distance 40 m Signal-to-Noise Ratio > 48 dB White Balance ATW, Anti Color Rolling, Manual Light Control ELC AGC ON/ OFF Electronic Shutter Auto, 1/ 50, 1/ 100, 1/ 250, 1/ 500, 1/ 1, 000, 1/ 2, 000, 1/ 4, 000, 1/ 10, 000 Day Night Auto / B/ W / Color Digital Noise Reduction Auto Back Light Compensation ON/ OFF Adaptive Tone-Curve Reproduction ON ( Luminance: 3steps, Contrast: 5steps) / OFF Privacy Zone up to 4 Zones Camera Title up to 52 alphanumeric characters ( 26x2) Mirror image ON / OFF Synchronization Internal Lens Focal Length 4 - 9 mm, 2.2x varifocal Angular Field of View H: 35° ( Tele) ~ 70° ( Wide) , V: 26° ( Tele) ~ 53° ( Wide) Input/ Output Video Output 1.0 V [ P-P] / 75 © , PAL composite videosignal ( BNC) General Setup Method OSD setup menu Language English, Russian, German, French, Spanish, Portuguese, Chinese, Japanese Safety/ EMC Standard CE ( EN61000-6-3, EN50130-4, EN61000-3-2, EN61000-3-3) FCC ( CFR 47 PART 15) Power Source and Power Consumption 12 V DC, 6W Ambient Operating Temperature – 10 ° C ~ + 50 ° C ( 14 ° F~ 122 ° F) Ambient Operating Humidity 85 % or less ( without condensation) Water and Dust Resistance IP66 Dimensions ø 139.5 mm x 97.5 mm ( H) Gross Weight ( approx.) 0.74 kg External Case Aluminum Alloy
